Arcon
Sugar processing requires significant resources. Transporting raw sugar is an abrasive procedure, and damage to conveyor belts could occur. This, in turn, impacts safety concerns in the factory, as fire and combustion need to be prevented. Ammeraal BelTech belts are constantly updated according to the latest developments from European food, health safety, and sanitation institutions.
Product features:
- Abrasion Resistant (ISO 5470-1)
- Compliance with EC and FDA
- Flame retardant (ISO 340)
- ATEX cat. 2 approved
- Anti-static (ISO 21178)
- Low elongation
- Possible with sealed edges
- Lightweight constructions
Typical application:
- Transport of refined sugar or other
granular products
- Trough, horizontal or inclined
conveyors
- Bucket elevators
| Article Code | Description | Belt thickness | Hardness top side | Info | |
| internal AB method KV.002 | according to ISO 868 | Minimum pulley diameter | |||
| total | top side | flexing | |||
| SBAR576279 | Arcon EF 24/3 10+20 white M1 AS FR FG | 6 mm | 85A Shore | 200 mm | Download |
| SBAR576299 | Arcon EF 50/3 15+30 white M1 AS FR FG | 9.5 mm | 85A Shore | 400 mm | Download |
| SBAR579259 | Arcon EF 16/2 10+20 white M1 AS FR FG | 5 mm | 85A Shore | 140 mm | Download |
Disclaimer: Product images are for representation purposes only. The actual part/product could differ based on individual requirements. Please contact us for more information.
