Circular pitch (also known as pitch) is an important factor in Synchro-Link Drives, just like in gear or chain drives. On the belt, pitch is the distance between tooth centers and is measured along the belt’s pitch line. Pitch is the distance between groove centers on the pulley and is measured using the pitch curve.
The pitch line of a Synchro-Link Drive Belt is found within the tension member. The pitch circle of a Synchro-Link Drive Belt pulley corresponds to the pitch line of the belt mating with it.
Synchro-Link Drive Belts must be used with pulleys of the same pitch. A belt of one pitch cannot be successfully utilized with pulleys of another pitch.
Attention: The internal data of table “133” is corrupted!
